60V Li Ion Battery Pack Testing Equipment Cell Management System for Lithium Battery

• Overview
• Product Description
• Product Key Features:
• Product Parameters
• Company Profile

Overview

Basic Info.

Model NO.	HD-5V400A
Type	Finished Batteries Tester
Test Region	All
Application	Lithium-ion Battery
Customized	Customized
Input Power Supply	AC380V
Chanrging Voltage	0V~60V
Discharging Voltage	6V~60V
Voltage Accuracy	±0.05%Fs
Voltage Resolution	1mv
Current Accuracy	±0.05%Fs
Current Resolution	1mA
Transport Package	Wooden Case
Trademark	HongDian
Origin	Dongguan
Production Capacity	1000pieces/Year

Product Description

Equipped to handle 60V Li-Ion battery packs, this testing equipment ensures thorough and precise assessment of each cell. The Cell Management System incorporated in this device brings an added layer of intelligence, allowing for efficient monitoring and control.
High Voltage Compatibility: Tailored for 60V Li-Ion battery packs, providing comprehensive testing capabilities for a wide range of applications.

Advanced Cell Management: The integrated Cell Management System enhances safety and performance by actively monitoring individual cells, managing voltage levels, and preventing issues such as overcharging or over-discharging.

Precision Testing: Accurate and reliable testing ensures that each battery pack meets the required standards for performance and longevity.

Versatile Application: Ideal for various lithium-ion battery applications, from electric vehicles to portable electronic devices, offering a versatile solution for different industries.

With our 60V Li-Ion Battery Pack Testing Equipment and Cell Management System, you can trust in a robust and intelligent solution that contributes to the efficiency and reliability of your lithium-ion battery systems.
AC Input Parameters

DC output parameters

Step Function Features / Function Features of Operation Steps

Protection Functions

Product Description Product Key Features: Product Parameters

Item	Technical Parameters
Wiring Method	AC380V Three-Phase Five-Wire System
Input Power Supply	AC380V
Power Factor	≥99%(full load)
THDi	≤5%(full load)
Maximum feedback efficiency	≥92%(full load)

Item	Technical Parameters
Voltage range	Charging Voltage: 0V ~ 60V Discharging Voltage: 6V ~ 60V
Voltage Accuracy	±0.05%FS
Voltage Resolution	1mV
Current Range	0 ~ 240A(customized)
Current Accuracy	±0.05%FS
Current Resolution	1mA
Current Response Time	10ms(10%FS ~ 90%FS)
Charge/Discharge Conversion Time	20ms(-90%FS ~ 90%FS)
Channel Control Mode	All channels can be independently controlled.
Auxiliary channels	Each channel is equipped with an auxiliary temperature channel.

Item	Technical Parameters
Minimum Data Logging Time	10ms
Editable Number of Steps	2000
Number of Step Cycles	65535
Step Cycle Nesting	5
Charge and Discharge Modes	Idle, Pause, Constant Current Charge (CC), Constant Voltage Charge (CV), Constant Resistance Charge (CR), Constant Current Constant Voltage Charge (CCCV), Constant Power Charge (CP), Constant Current Discharge (DC), Constant Power Discharge (DP), Constant Resistance Discharge (DR), Direct Current Internal Resistance Test (DCIR)
Termination Criteria	Voltage, Current, Capacity, Energy, Time, Power, Cycle Count, BMS Parameters, Custom Advanced Parameters (Supporting Single or Multiple Logic AND/OR Combinations)
Execution Action Types	Jump, Pause, Protect, Next Step
Importing DBC Files	Supports File Editing, Saving, and Importing
Direct Current Internal Resistance Testing (DCIR)	Supports DCIR (Direct Current Internal Resistance) test steps, hardware real-time calculation, and supports two types of tests: (V1-V2)/(I1-I2) and (V1-V2)/I.
Data Export Methods	Export data in Excel and CSV formats.

Item	Technical Parameters
AC-Side Protection	AC Grid Voltage Over/Under Voltage Protection, Surge Protection, Anti-Islanding Protection, Over/Under Frequency Protection, Hardware Overtemperature Protection, Self-Test Protection, etc.
DC-Side Protection	Bus Over/Under Voltage Protection, Hardware Overtemperature Protection, Battery Channel Line Reverse Connection Protection, etc.
Battery-Side Comprehensive Protection	Battery pack total voltage upper/lower limit protection, battery cell voltage upper/lower limit protection, battery temperature upper/lower limit protection, battery charge/discharge current upper limit protection, battery capacity upper/lower limit protection, BMS communication loss protection, network disconnection protection, etc.
Ingress Protection (IP) Rating	IP22
Operating Temperature Range	0ºC~ 45ºC
Cooling Method	Forced Air Cooling
Sound Level	≤75dB

Company Profile

Shenzhen Hongda New Energy Co., Ltd. Was founded in 2014, is a research and development, production and sales in one of the battery module testing equipment and testing technology suppliers. The company′s "Hongdian" brand is committed to the research and development, production and sales of energy storage, power lithium battery pack aging detection equipment. Over the years, the company′s business has grown steadily, and the office and production environment has reached more than 6, 000 square meters. The company has energy-saving feedback technology, battery management and control, battery pack system integration and other technologies. The company mainly serves energy storage, power and other lithium battery PACK manufacturers. With the development of business, the company′s products are constantly enriched, including energy storage, power lithium battery pack aging detection equipment, high voltage, high current, high-power battery test equipment, power battery pack, energy storage power station, mobile base station standby power supply and other new energy projects of battery charging and discharging comprehensive testing equipment.
